GeometryPrimitiveNodesImageTexture.x3d (X3dToXhtml)

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.1//EN"   "http://www.web3d.org/specifications/x3d-3.1.dtd">

<X3D profile='Immersive' version='3.1' xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation=' http://www.web3d.org/specifications/x3d-3.1.xsd '>

<head>

<meta name='title' content='GeometryPrimitiveNodesImageTexture.x3d'/>
<meta name='description' content='Geometry Primitive Nodes: Shape, Box, Cone, Cylinder, Sphere, Text, FontStyle, with ImageTexture applied'/>
<meta name='creator' content='Don Brutzman'/>
<meta name='created' content='25 March 2005'/>
<meta name='modified' content='22 February 2008'/>
<meta name='rights' content='Copyright (c) Don Brutzman and Len Daly, 2005'/>
<meta name='identifier' content=' http://X3dGraphics.com/examples/X3dForWebAuthors/Chapter05-AppearanceMaterialTextures/GeometryPrimitiveNodesImageTexture.x3d '/>
<meta name='reference' content=' http://X3dGraphics.com/examples/X3dForWebAuthors/Chapter02-GeometryPrimitives/GeometryPrimitiveNodes-White.x3d '/>
<meta name='generator' content='X3D-Edit, https://savage.nps.edu/X3D-Edit'/>
<meta name='license' content='../license.html'/>

</head>
<!--

Index for DEF nodes: DefaultAppearance, DefaultBox, DefaultCone, DefaultCylinder, DefaultFontStyle, DefaultMaterial, DefaultShape, DefaultSphere, DefaultText, earth-topo

-->
<Scene>

<Background skyColor='1 1 1'/>
<Transform translation='-5 0 0'>

<Shape DEF='DefaultShape'>

<Box DEF='DefaultBox'/>
<Appearance DEF='DefaultAppearance'>

<Material diffuseColor='1 0.2 0.2'/>
<ImageTexture DEF='earth-topo'
url=' "../Chapter01-TechnicalOverview/earth-topo.png" "../Chapter01-TechnicalOverview/earth-topo.jpg" "../Chapter01-TechnicalOverview/earth-topo-small.gif" "http://www.web3d.org/x3d/content/examples/Basic/earth-topo.png" "http://www.web3d.org/x3d/content/examples/Basic/earth-topo.jpg" "http://www.web3d.org/x3d/content/examples/Basic/earth-topo-small.gif" '/>

</Appearance>

</Shape>

</Transform>
<Transform translation='-2.5 0 0'>

<Shape>

<Cone DEF='DefaultCone'/>
<Appearance>

<Material diffuseColor='0.2 1 0.2'/>
<ImageTexture USE='earth-topo'/>

</Appearance>

</Shape>

</Transform>
<Transform>

<Shape>

<Cylinder DEF='DefaultCylinder'/>
<Appearance>

<Material diffuseColor='0.2 0.2 1'/>
<ImageTexture USE='earth-topo'/>

</Appearance>

</Shape>

</Transform>

<Transform rotation='0 1 0 -1.57' translation='2.5 0 0'>

<Shape>

<Sphere DEF='DefaultSphere'/>
<Appearance>

<Material diffuseColor='1 1 0.2'/>
<ImageTexture USE='earth-topo'/>

</Appearance>

</Shape>

</Transform>
<Transform translation='5 0 0'>

<Shape>

<Text DEF='DefaultText' length='0' solid='false' string='"Learn" "X3D!"'>

<FontStyle DEF='DefaultFontStyle' family='SERIF' justify='"MIDDLE" "MIDDLE"'/>

</Text>
<Appearance>

<Material DEF='DefaultMaterial' ambientIntensity='0.33' diffuseColor='0.237059 0.096273 0.215625' shininess='0.13' specularColor='0.311358 0.387879 0.387879'/>

</Appearance>

</Shape>

</Transform>

</Scene>

</X3D>
<!--

Index for DEF nodes: DefaultAppearance, DefaultBox, DefaultCone, DefaultCylinder, DefaultFontStyle, DefaultMaterial, DefaultShape, DefaultSphere, DefaultText, earth-topo

-->
