<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.3//EN" "https://www.web3d.org/specifications/x3d-3.3.dtd">
<X3D profile='Interactive' version='3.3'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation =' https://www.web3d.org/specifications/x3d-3.3.xsd '>
<head>
<meta name='title' content='StripedSurfPerchPlaque.x3d'/>
<meta name='creator' content='Michael Collins'/>
<meta name='created' content='18 February 2001'/>
<meta name='modified' content='20 October 2019'/>
<meta name=' warning ' content=' under development '/>
<meta name='description' content='One fish plaque with lithograph on one side and actual picture on the back. Click on plaque to go to picture or click on buttons to change picture.'/>
<meta name='identifier' content=' https://X3dGraphics.com/examples/X3dForWebAuthors/KelpForestExhibit/StripedSurfPerchPlaque.x3d '/>
<meta name='generator' content='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
<meta name='Image' content='StripedSurfPerchPatch.jpg'/>
<meta name='Image' content='RainbowSurfPerch002.jpg'/>
<meta name='license' content=' ../license.html'/>
</head>
<!--
Index for DEF nodes : BASE_TRANSFORM, BaseTouchSensor, BLUEROCKFISH_TRANSFORM, BLUEROCKFISHCLOCK, BlueRockfishPathInterpolator, BlueRockfishTouchSensor, BUTTON_TRANSFORM, BUTTON_TRANSFORM2, FrontTouchSensor, FRONTTOUCHSENSORCLOCK, PictureTouchSensor, PlaqueToPictureInterpolator, stripedsurfperch
Index for Viewpoint image : stripedsurfperch
-->
<Scene>
<WorldInfo title='StripedSurfPerchPlaque.x3d'/>
<Viewpoint DEF='stripedsurfperch' description='Striped Surf Perch' position='0 0 4'/>
<!-- Fish Plaques -->
<Group>
<!-- ROUTE information for BlueRockfishTouchSensor node:  [from touchTime to BLUEROCKFISHCLOCK.set_startTime ] -->
 <TouchSensor DEF='BlueRockfishTouchSensor' description='touch to rotate'/>
<!-- ROUTE information for BLUEROCKFISHCLOCK node:  [from BlueRockfishTouchSensor.touchTime to set_startTime ] [from PictureTouchSensor.touchTime to set_startTime ] [from fraction_changed to BlueRockfishPathInterpolator.set_fraction ] -->
 <TimeSensor DEF='BLUEROCKFISHCLOCK' cycleInterval='2'/>
<!-- ROUTE information for BlueRockfishPathInterpolator node:  [from BLUEROCKFISHCLOCK.fraction_changed to set_fraction ] [from value_changed to BLUEROCKFISH_TRANSFORM.set_rotation ] -->
 <OrientationInterpolator DEF='BlueRockfishPathInterpolator' key='0.0 0.50 1.0' keyValue='0.0 1.0 0.0 0.0 0.0 1.0 0.0 1.57 0.0 1.0 0.0 3.14'/>
<!-- ROUTE information for BLUEROCKFISH_TRANSFORM node:  [from BlueRockfishPathInterpolator.value_changed to set_rotation ] [from PlaqueToPictureInterpolator.value_changed to set_rotation ] -->
 <Transform DEF='BLUEROCKFISH_TRANSFORM'>
<Shape>
<Box size='4 2 .1'/>
<Appearance>
<ImageTexture
  url=' "StripedSurfPerchPatch.jpg" "https://X3dGraphics.com/examples/X3dForWebAuthors/KelpForestExhibit/StripedSurfPerchPatch.jpg" '/>
</Appearance>
</Shape>
<Transform translation='0 0 -.1'>
<Shape>
<Box size='4 2 .2'/>
<Appearance>
<ImageTexture
  url=' "RainbowSurfPerch002.jpg" "https://X3dGraphics.com/examples/X3dForWebAuthors/KelpForestExhibit/RainbowSurfPerch002.jpg" '/>
</Appearance>
</Shape>
</Transform>
</Transform>
<Group>
<Transform DEF='BUTTON_TRANSFORM' translation='1 2 0'>
<Shape>
<Sphere radius='.5'/>
<Appearance>
<Material diffuseColor='0 1 0'/>
</Appearance>
</Shape>
</Transform>
<!-- ROUTE information for FrontTouchSensor node:  [from touchTime to FRONTTOUCHSENSORCLOCK.set_startTime ] -->
 <TouchSensor DEF='FrontTouchSensor' description='front TouchSensor'/>
<!-- ROUTE information for FRONTTOUCHSENSORCLOCK node:  [from FrontTouchSensor.touchTime to set_startTime ] [from fraction_changed to PlaqueToPictureInterpolator.set_fraction ] -->
 <TimeSensor DEF='FRONTTOUCHSENSORCLOCK' cycleInterval='2'/>
<!-- ROUTE information for PlaqueToPictureInterpolator node:  [from FRONTTOUCHSENSORCLOCK.fraction_changed to set_fraction ] [from value_changed to BLUEROCKFISH_TRANSFORM.set_rotation ] -->
 <OrientationInterpolator DEF='PlaqueToPictureInterpolator' key='0.0 0.50 1.0' keyValue='0.0 1.0 0.0 3.14 0.0 1.0 0.0 1.57 0.0 1.0 0.0 0.00'/>
</Group>
<Group>
<Transform DEF='BUTTON_TRANSFORM2' translation='-1 2 0'>
<Shape>
<Sphere radius='.5'/>
<Appearance>
<Material diffuseColor='1 0 0'/>
</Appearance>
</Shape>
</Transform>
<!-- ROUTE information for PictureTouchSensor node:  [from touchTime to BLUEROCKFISHCLOCK.set_startTime ] -->
 <TouchSensor DEF='PictureTouchSensor' description='picture TouchSensor'/>
</Group>
<Group>
<Transform DEF='BASE_TRANSFORM' translation='0 0 -.3'>
<Shape>
<Box size='8 6 .3'/>
<Appearance>
<Material diffuseColor='.3 .3 .6'/>
</Appearance>
</Shape>
</Transform>
<TouchSensor DEF='BaseTouchSensor' description='touch to rotate'/>
<Group>
<Transform translation='0 -2.6 0'>
<Shape>
<Box size='8 1 1'/>
<Appearance>
<Material diffuseColor='0.8 0.8 0.2'/>
</Appearance>
</Shape>
</Transform>
</Group>
<Group>
<Transform translation='0 2.6 0'>
<Shape>
<Box size='8 1 1'/>
<Appearance>
<Material diffuseColor='0.8 0.8 0.2'/>
</Appearance>
</Shape>
</Transform>
</Group>
<Group>
<Transform rotation='0 0 1 1.58' translation='3.6 0 0'>
<Shape>
<Box size='6.2 1 1'/>
<Appearance>
<Material diffuseColor='0.8 0.8 0.2'/>
</Appearance>
</Shape>
</Transform>
</Group>
<Group>
<Transform rotation='0 0 1 1.58' translation='-3.6 0 0'>
<Shape>
<Box size='6.2 1 1'/>
<Appearance>
<Material diffuseColor='0.8 0.8 0.2'/>
</Appearance>
</Shape>
</Transform>
</Group>
</Group>
</Group>
<ROUTE fromNode='BlueRockfishTouchSensor' fromField='touchTime' toNode='BLUEROCKFISHCLOCK' toField='set_startTime'/>
<ROUTE fromNode='BLUEROCKFISHCLOCK' fromField='fraction_changed' toNode='BlueRockfishPathInterpolator' toField='set_fraction'/>
<ROUTE fromNode='BlueRockfishPathInterpolator' fromField='value_changed' toNode='BLUEROCKFISH_TRANSFORM' toField='set_rotation'/>
<ROUTE fromNode='FrontTouchSensor' fromField='touchTime' toNode='FRONTTOUCHSENSORCLOCK' toField='set_startTime'/>
<ROUTE fromNode='FRONTTOUCHSENSORCLOCK' fromField='fraction_changed' toNode='PlaqueToPictureInterpolator' toField='set_fraction'/>
<ROUTE fromNode='PlaqueToPictureInterpolator' fromField='value_changed' toNode='BLUEROCKFISH_TRANSFORM' toField='set_rotation'/>
<!-- Picture touch sensor only has to tie into the BLUEROCKFISHCLOCK so that it will turn picture. -->
<ROUTE fromNode='PictureTouchSensor' fromField='touchTime' toNode='BLUEROCKFISHCLOCK' toField='set_startTime'/>
</Scene>
</X3D>
<!--
