<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.3//EN" "https://www.web3d.org/specifications/x3d-3.3.dtd">
<X3D profile='Immersive' version='3.3 xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation =' https://www.web3d.org/specifications/x3d-3.3.xsd '>
<head>
<meta name='titlecontent='ExtrusionPentagonCrossSectionItssTexture.x3d'/>
<meta name='descriptioncontent='Comparison of Extrusion, ExtrusionCrossSectionPrototype, ExtrusionCrossSectionITSSPrototype for Texture Mapping.'/>
<meta name='creatorcontent='Don Brutzman and Sungmin Kwon'/>
<meta name='contributorcontent='Naval Postgraduate School'/>
<meta name='createdcontent='23 October 2017'/>
<meta name='modifiedcontent='20 October 2019'/>
<meta name='subjectcontent='Extrusion, ExtrusionCrossSectionPrototype, ExtrusionCrossSectionITSSPrototype with Textrue Image'/>
<meta name='identifiercontent=' https://X3dGraphics.com/examples/X3dForWebAuthors/Chapter06GeometryPointsLinesPolygons/ExtrusionPentagonCrossSectionItssTexture.x3d '/>
<meta name='generatorcontent='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
<meta name='licensecontent=' ../license.html'/>
</head>
<!--

Index for ExternProtoDeclare definitions : ExtrusionCrossSection, ExtrusionCrossSectionITSS

Index for DEF nodes : CenterFontStyle, ExamineMode, FlyPanNavigation, PentagonExtrusion, PentagonExtrusionITSS, Title

Index for Viewpoint images : Viewpoint_1, Viewpoint_2, Viewpoint_3
-->
<Scene>
<WorldInfo title='ExtrusionPentagonCrossSectionItssTexture.x3d'/>
<NavigationInfo DEF='ExamineMode'/>
<NavigationInfo DEF='FlyPanNavigationtype='"FLY" "ANY"'/>
<Background skyColor='1 1 1'/>
<Viewpoint description='Oblique view from aboveorientation='-1 0.015 -0.006 0.78position='0.25 14 14'/>
<Viewpoint description='Extrusion Pentagonorientation='-1 0 0 0.2position='0 4 16'/>
<Viewpoint description='Overhead vieworientation='1 0 0 -1.57position='0 27 0'/>
<Background groundColor='0.9 0.9 0.9skyColor='0.9 0.9 0.9'/>
<!-- Title -->
<Transform rotation='1 0 0 -1.3translation='0 2 -9'>
<Shape>
<Text DEF='Titlestring='"Comparison of Extrusion Based Structure with Texture Map"'>
<FontStyle justify='"MIDDLE" "MIDDLE"'/>
</Text>
<Appearance>
<Material diffuseColor='0 0 0'/>
</Appearance>
</Shape>
</Transform>
<!-- Extrusion Node -->
<Transform translation='-4 0 -4'>
<Shape>
<Extrusion beginCap='falsecrossSection='-3.5 -1 -2.1 2.9 2.2 2.9 3.6 -1 0 -3.5 -3.5 -1endCap='falsescale='1 1 1 1 0.2 0.2spine='0 0 0 0 1 0 0 1.6 0'/>
<Appearance>
<Material diffuseColor='0.2 0.6 0.5'/>
<ImageTexture
  url=' "../earth-topo.png" "https://X3dGraphics.com/examples/X3dForWebAuthors/earth-topo.png" '/>
</Appearance>
</Shape>
<Transform rotation='1 0 0 -1.3translation='0 0 2.9'>
<Shape>
<Text string='"Extrusion Node"'>
<FontStyle DEF='CenterFontStylejustify='"MIDDLE" "BEGIN"size='0.6style='BOLD'/>
</Text>
<Appearance>
<Material diffuseColor='0 0 0'/>
</Appearance>
</Shape>
</Transform>
</Transform>
<!-- ExtrusionCrossSection Prototype Node -->
<ExternProtoDeclare name='ExtrusionCrossSectionappinfo='Shape prototype for Extrusion node that also draws spine line plus oriented scaled cross sections at each spine point' documentation=' https://X3dGraphics.com/examples/X3dForWebAuthors/Chapter06GeometryPointsLinesPolygons/ExtrusionCrossSectionPrototype.x3d '
  url=' "ExtrusionCrossSectionPrototype.x3d#ExtrusionCrossSection" "https://X3dGraphics.com/examples/X3dForWebAuthors/Chapter06GeometryPointsLinesPolygons/ExtrusionCrossSectionPrototype.x3d#ExtrusionCrossSection" "ExtrusionCrossSectionPrototype.wrl#ExtrusionCrossSection" "https://X3dGraphics.com/examples/X3dForWebAuthors/Chapter06GeometryPointsLinesPolygons/ExtrusionCrossSectionPrototype.wrl#ExtrusionCrossSection" '>
<field name='nametype='SFStringaccessType='initializeOnly'
 appinfo='Extrusion name'/>

<field name='crossSectiontype='MFVec2faccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='spinetype='MFVec3faccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='scaletype='MFVec2faccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='orientationtype='MFRotationaccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='beginCaptype='SFBoolaccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='endCaptype='SFBoolaccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='ccwtype='SFBoolaccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='convextype='SFBoolaccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='creaseAngletype='SFFloataccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='solidtype='SFBoolaccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='extrusionImageTexturetype='SFNodeaccessType='initializeOnly'
 appinfo='Image to apply to Extrusion'/>

<field name='extrusionTextureTransformtype='SFNodeaccessType='initializeOnly'
 appinfo='TextureTransform coordinates of image applied to Extrusion'/>

<field name='set_crossSectiontype='MFVec2faccessType='inputOnly'
 appinfo='Extrusion field'/>

<field name='set_spinetype='MFVec3faccessType='inputOnly'
 appinfo='Extrusion field'/>

<field name='set_scaletype='MFVec2faccessType='inputOnly'
 appinfo='Extrusion field'/>

<field name='set_orientationtype='MFRotationaccessType='inputOnly'
 appinfo='Extrusion field'/>

<field name='traceEnabledtype='SFBoolaccessType='initializeOnly'
 appinfo='Whether to provide initialization trace statements showing node construction'/>

<field name='spineColortype='SFColoraccessType='inputOutput'
 appinfo='emissiveColor of spine'/>

<field name='crossSectionColortype='SFColoraccessType='inputOutput'
 appinfo='diffuseColor of crossSection'/>

<field name='crossSectionTransparencytype='SFFloataccessType='inputOutput'
 appinfo='transparency of crossSection'/>

<field name='extrusionColortype='SFColoraccessType='inputOutput'
 appinfo='diffuseColor of extrusion hull'/>

<field name='extrusionTransparencytype='SFFloataccessType='inputOutput'
 appinfo='transparency of extrusion hull'/>
</ExternProtoDeclare>
<Transform translation='4 0 -4'>
<ProtoInstance name='ExtrusionCrossSectionDEF='PentagonExtrusion'>
<fieldValue name='namevalue='PentagonExtrusion'/>
<fieldValue name='crossSectionvalue='-3.5 -1 -2.1 2.9 2.2 2.9 3.6 -1 0 -3.5 -3.5 -1'/>
<fieldValue name='spinevalue='0 0 0 0 1 0 0 1.6 0'/>
<fieldValue name='scalevalue='1 1 1 1 0.2 0.2'/>
<fieldValue name='creaseAnglevalue='3'/>
<fieldValue name='ccwvalue='true'/>
<fieldValue name='extrusionImageTexture'> </fieldValue>
<fieldValue name='spineColorvalue='0.7 0.7 0'/>
<fieldValue name='crossSectionColorvalue='0.6 0.6 0.2'/>
<fieldValue name='extrusionColorvalue='0.2 0.6 0.5'/>
<fieldValue name='extrusionTransparencyvalue='0.0'/>
<fieldValue name='traceEnabledvalue='false'/>
</ProtoInstance>
<Transform rotation='1 0 0 -1.3translation='0 0 3'>
<Shape>
<Text string='"ExtrusionCrossSection" "Prototype"'>
<FontStyle USE='CenterFontStyle'/>
</Text>
<Appearance>
<Material diffuseColor='0 0 0'/>
</Appearance>
</Shape>
</Transform>
</Transform>
<!-- ExtrusionCrossSectionITSS Prototype Node -->
<ExternProtoDeclare name='ExtrusionCrossSectionITSS'
  url=' "ExtrusionCrossSectionITSSPrototype.x3d#ExtrusionCrossSectionITSS" "https://X3dGraphics.com/examples/X3dForWebAuthors/Chapter06GeometryPointsLinesPolygons/ExtrusionCrossSectionITSSPrototype.x3d#ExtrusionCrossSectionITSS" "ExtrusionCrossSectionITSSPrototype.wrl#ExtrusionCrossSectionITSS" "https://X3dGraphics.com/examples/X3dForWebAuthors/Chapter06GeometryPointsLinesPolygons/ExtrusionCrossSectionITSSPrototype.wrl#ExtrusionCrossSectionITSS" '>
<field name='nametype='SFStringaccessType='initializeOnly'
 appinfo='Extrusion name'/>

<field name='crossSectiontype='MFVec2faccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='spinetype='MFVec3faccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='scaletype='MFVec2faccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='orientationtype='MFRotationaccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='beginCaptype='SFBoolaccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='endCaptype='SFBoolaccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='ccwtype='SFBoolaccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='convextype='SFBoolaccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='creaseAngletype='SFFloataccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='solidtype='SFBoolaccessType='initializeOnly'
 appinfo='Extrusion field'/>

<field name='extrusionImageTexturetype='SFNodeaccessType='initializeOnly'
 appinfo='Image to apply to Extrusion'/>

<field name='extrusionTextureTransformtype='SFNodeaccessType='initializeOnly'
 appinfo='TextureTransform coordinates of image applied to Extrusion'/>

<field name='set_crossSectiontype='MFVec2faccessType='inputOnly'
 appinfo='Extrusion field'/>

<field name='set_spinetype='MFVec3faccessType='inputOnly'
 appinfo='Extrusion field'/>

<field name='set_scaletype='MFVec2faccessType='inputOnly'
 appinfo='Extrusion field'/>

<field name='set_orientationtype='MFRotationaccessType='inputOnly'
 appinfo='Extrusion field'/>

<field name='traceEnabledtype='SFBoolaccessType='initializeOnly'
 appinfo='Whether to provide initialization trace statements showing node construction'/>

<field name='spineColortype='SFColoraccessType='inputOutput'
 appinfo='emissiveColor of spine'/>

<field name='crossSectionColortype='SFColoraccessType='inputOutput'
 appinfo='diffuseColor of crossSection'/>

<field name='crossSectionTransparencytype='SFFloataccessType='inputOutput'
 appinfo='transparency of crossSection'/>

<field name='extrusionColortype='SFColoraccessType='inputOutput'
 appinfo='diffuseColor of extrusion hull'/>

<field name='extrusionTransparencytype='SFFloataccessType='inputOutput'
 appinfo='transparency of extrusion hull'/>
</ExternProtoDeclare>
<Transform translation='0 0 3.5'>
<ProtoInstance name='ExtrusionCrossSectionITSSDEF='PentagonExtrusionITSS'>
<fieldValue name='namevalue='PentagonExtrusionITSS'/>
<fieldValue name='crossSectionvalue='-3.5 -1 -2.1 2.9 2.2 2.9 3.6 -1 0 -3.5 -3.5 -1'/>
<fieldValue name='spinevalue='0 0 0 0 1 0 0 1.6 0'/>
<fieldValue name='scalevalue='1 1 1 1 0.2 0.2'/>
<fieldValue name='ccwvalue='true'/>
<fieldValue name='extrusionImageTexture'> </fieldValue>
<fieldValue name='spineColorvalue='0.7 0.7 0'/>
<fieldValue name='crossSectionColorvalue='0.6 0.6 0.2'/>
<fieldValue name='extrusionColorvalue='0.2 0.6 0.5'/>
<fieldValue name='extrusionTransparencyvalue='0.0'/>
<fieldValue name='traceEnabledvalue='false'/>
</ProtoInstance>
<Transform rotation='1 0 0 -1.5translation='0 0 3.2'>
<Shape>
<Text string='"ExtrusionCrossSectionITSS Prototype"'>
<FontStyle USE='CenterFontStyle'/>
</Text>
<Appearance>
<Material diffuseColor='0 0 0'/>
</Appearance>
</Shape>
</Transform>
</Transform>
</Scene>
</X3D>
<!--
