<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.3//EN" "https://www.web3d.org/specifications/x3d-3.3.dtd">

<X3D profile='Immersive' version='3.3' xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation =' https://www.web3d.org/specifications/x3d-3.3.xsd '>

<head>

<meta name='title' content='GaribaldiRemoteNoTexture.x3d'/>
<meta name='description' content='Instantiate the Garibaldi fish prototype using a remote skin texture file.'/>
<meta name='creator' content='Ildeniz Duman'/>
<meta name='created' content='1 June 1998'/>
<meta name='modified' content='20 October 2019'/>
<meta name='reference' content=' https://X3dGraphics.com/examples/X3dForWebAuthors/KelpForestExhibit/Garibaldi.x3d '/>
<meta name='identifier' content=' https://X3dGraphics.com/examples/X3dForWebAuthors/Chapter05AppearanceMaterialTextures/GaribaldiRemoteNoTexture.x3d '/>
<meta name='generator' content='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
<meta name='license' content=' ../license.html'/>

</head>
<!--

Index for ExternProtoDeclare definition : CircleFish

Index for Viewpoint image : Viewpoint_1

-->
<Scene>

<WorldInfo title='GaribaldiRemoteNoTexture.x3d'/>
<ExternProtoDeclare name='CircleFish'
url=' "CircleFishPrototype.x3d#CircleFish" "https://X3dGraphics.com/examples/X3dForWebAuthors/Chapter05AppearanceMaterialTextures/CircleFishPrototype.x3d#CircleFish" "https://X3dGraphics.com/examples/X3dForWebAuthors/KelpForestExhibit/CircleFishPrototype.x3d#CircleFish" "CircleFishPrototype.wrl#CircleFish" "https://X3dGraphics.com/examples/X3dForWebAuthors/Chapter05AppearanceMaterialTextures/CircleFishPrototype.wrl#CircleFish" "https://X3dGraphics.com/examples/X3dForWebAuthors/KelpForestExhibit/CircleFishPrototype.wrl#CircleFish" '>

<field name='skinTextureUrl' type='MFString' accessType='inputOutput'/>
<field name='fishScale' type='SFVec3f' accessType='inputOutput'/>
<field name='fishColor' type='SFColor' accessType='inputOutput'/>
<field name='finColor' type='SFColor' accessType='inputOutput'/>
<field name='positionKey' type='MFFloat' accessType='inputOutput'/>
<field name='positionKeyValue' type='MFVec3f' accessType='inputOutput'/>
<field name='orientationKey' type='MFFloat' accessType='inputOutput'/>
<field name='orientationKeyValue' type='MFRotation' accessType='inputOutput'/>
<field name='orbitTime' type='SFTime' accessType='inputOutput'/>

</ExternProtoDeclare>
<Viewpoint description='Garibaldi' orientation='0.0 1.0 0.0 120.0' position='2.0 0.0 2.0'/>
<ProtoInstance name='CircleFish'>

<fieldValue name='skinTextureUrl' value=' "https://X3dGraphics.com/examples/X3dForWebAuthors/KelpForestExhibit/GaribaldiPatch.jpg" '/>
<fieldValue name='fishScale' value='1.0 0.39 0.4'/>
<fieldValue name='finColor' value='0.9 0.66 0.4'/>
<fieldValue name='fishColor' value='.97 .75 .3'/>
<fieldValue name='positionKey' value='0.0 0.4 0.7 0.95 1.0'/>
<fieldValue name='positionKeyValue' value='0.0 0.0 0.0 0.5 0.0 0.0 0.0 0.0 0.0 0.5 0.0 0.0 0.2 0.0 0.0'/>
<fieldValue name='orientationKey' value='0.0 1.0'/>
<fieldValue name='orientationKeyValue' value='0.0 1.0 0.0 90.0 0.0 1.0 0.0 90.0'/>
<fieldValue name='orbitTime' value='80.0'/>

</ProtoInstance>

</Scene>

</X3D>
<!--
